Standard features

• Print methods: Thermal transfer or direct thermal
• Construction: Steel frame and cabinet with metal interior components
• Single-level Element Energy Equalizer™ (E 3 ™)for superior print quality
• Fast 32-bit processing
• Selectable print speeds up to 8”/second
• Transmissive media sensor
• Standard 2-line, 16-character LCD control panel
• Internal real-time clock
• Unicode™ compliant
• XML-Enabled printing—direct-connect integration for bar code label printing; eliminates license fees and print server hardware and lowers customization and programming costs

Print speed

• 305 mm/sec

Print width

• 104 mm

Print length

• 203 dpi: 3810 mm
• 300 dpi: 2450 mm

Resolution

• 203 dpi
• 300 dpi

Memory

• Standard: 512 MB SDRAM; 2 GIG Flash

Media sensors

• Transmissive (standard) and reflective

Media characteristics

• Maximum label and liner width 20 mm to 114 mm
• Maximum label and liner length 991 mm
• Maximum roll diameter 203 mm O.D.
• Core diameter 76 mm I.D. core
• Media thickness .076 mm to .305 mm
• Media types continuous, die-cut, notch, black mark

Ribbon characteristics

• Outside diameter 81.3 mm
• Standard length 300 m to 450 m
• Ratio 2:1 and 3:1 media roll to ribbon
• Ribbon width 51 mm to 110 mm. Ribbon is recommended to be at least as wide as media
• ID Core 25.4 mm

Firmware

• ZPI 2.0™
• ZPL/ZPL2® (Contact Zebra Development Services for additional details)
• XML-Enabled printing

Fonts and graphics

16 resident expandable ZPL II bitmap and two resident scalable ZPL fonts
Asian and other international scalable and smooth bitmapped fonts
Unicode™: For multi-language printing
Downloadable objects include graphics, scalable and bitmap fonts, label templates
and formats
IBM Code Page 850 international character sets are available in the fonts A, B, C, D,
E, F, G and 0 through software control
Code Page 1250, 1252, 1253, 1254, 1255 Support with font 0
32 MB user available DRAM
512 MB user available on-board Flash

Barcode symbologies

Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC
Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit
extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5,
Logmars, MSI, Codabar, Planet Code
2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39,
MicroPDF, RSS-14 (and composite), Aztec

Physical characteristics

• Width: 268.2mm
• Depth: 512.3mm
• Height: 395.68mm
• Weight: 22.7kg's

Options

Connectivity
• Two open communication slots to add internal cards for 802.11ac with Bluetooth
4.0, parallel, USB Host. IPv6 option is available as an external dongle attached to
a parallel port

Media Handling
• Rewind: Internally rewinds a full roll of printed labels on 3" core, or peels and
rewinds liner
• Cutter: Front-mount guillotine cutter and catch tray

Keyboard Display Unit
• ZKDU™ keyboard display units for stand-alone printing applications

Communication and interface capabilities

• Centronics ®  RS-232 RS-422*, and RS-485* serial ports; IEEE 1284 bi-directional parallel

Please Note: specifications and options vary according to printer model and are subject to change without prior notice.
