Print method

• Inkjet.

Print resolutions

• 4800 x 1200 dpi
• 1200 x 1200 dpi
• 600 x 600 dpi.

Ink cartridges

• Colour (CMY), Process Black (K).

Colours

• 16.7 million.

Colour matching

• Z-Colour™ Colour Matching Software.

Print width

• 19mm to 101.6mm.

Print length

• 19mm to 609.6mm.

Media width

• 25.4mm to 108mm.

Media types

• Roll-fed pressure-sensitive labels, roll-fed tags, fan-fold labels or tags.

Media sensing

• Moveable see-through sensor for die-cut labels.
• Reflective for labels and tags with black stripe.
• Continuous label stock.
• Preprinted label stock.

Supply roll

• 127mm maximum diameter on 50.8mm core. Core has additional restrictions – see manual

Ink level warning

• Calculates actual number of prints remaining based upon ink usage of graphics being printed (patent-pending)

Indicator lights

• Power, Ink.

Controls

• Pause, Load/Feed, Unload

Operating systems

•  Windows® XP/2000/Vista/7 or Mac® OS X, 10.2 or higher up to 10.12.

Recommended minimum system

• For PC: Pentium® IV computer or better, 512MB RAM, 5GB free hard drive space, USB 2.0 or USB 1.1.
• For Mac: 700 Mhz G4 or higher with 512MB RAM, 5GB free hard drive space, USB 2.0 or USB 1.1.

Label design software

•  NiceLabel™ SE Primera Edition included.
• Can also be used with most other popular label design software programs.

Electrical rating

• 12VDC, 5.0A.

Power requirements

• 100-240VAC, 50/60 Hz, 60 watts.

Certifications

• UL, UL-C, CE, FCC Class A.

Weight

• 3.2 kg.

Dimensions

•  264mm (W) x 389mm (D) x 180mm (H - closed), 442mm (H -open).

Options:

• Media Cutter, #74263; Ink Cartridge, #53376.

Need to make larger labels?

The LX900 Colour Label Printer offers all of the same great features of our LX400 but prints larger labels up to a maximum width of 203mm.
