Honeywell Xenon 1902g-bf Wireless Barcode Scanner

Code: 161902GBF

Honeywell Xenon 1902g-bf Wireless Barcode Scanner

The Honeywell Xenon™ 1902g-bf area-imager scanner incorporates the latest in battery-free technology, offering the freedom of Bluetooth® low-
energy wireless technology without the maintenance hassles or long recharge time associated with traditional batteries. Like all other Xenon
scanners, the 1902g-bf scanner delivers aggressive barcode scanning performance – even on poor-quality or damaged barcodes.

An integrated Bluetooth low-energy Class 2 radio gives users complete freedom of movement up to 10 meters (33 feet) from the base in a typical work environment. For added convenience, a paging system on the base activates auditory signals that help to locate a misplaced scanner. By eliminating the trip-hazard of tethered cables, the Xenon 1902g-bf scanner can provide a safer and more productive environment.

FEATURES:

Fast Charging - The Xenon 1902g-bf scanner is fully charged in under two minutes with a simple USB connection, and
under 30 seconds when a powered USB or external power supply is used.
Long Use Life - When fully charged, the Xenon 1902g-bf scanner can typically scan over 450 UPC/EAN codes without the
need for recharging – more than enough to check out 25 customers during peak times, or scan
a morning’s worth of overnight deliveries.
Stays Charged Longer - Super-capacitors hold their charge for hours when fully charged. So operators who forget to place their scanner in the charger prior to break won’t impact operations upon return.
Programmable Recharge Alerts - Two fully independently configurable recharge alerts remind the operator to place the scanner back into
the base for charging. The alerts can be configured to trigger at different levels of discharge and with different levels of urgency, ensuring continuous operation.

PHYSICAL CHARACTERISTICS

Scanner:

Dimensions: 104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)

Weight: 195 g (6.9 oz)

Operating Power: N /A

Non-Charging Power: N /A

Host System Interface: N /A

Charge and Communication Base:

Dimensions: 132 mm x 102 mm x 81 mm (5.2 in x 4 in x 3.2 in)

Weight: 180 g (6.3 oz)

Operating Power: 5W (1A @ 5V)

Non-Charging Power: 0.5W (0.1A @ 5V)

Host System Interface: USB, Keyboard Wedge, RS-232, IBM 46xx (RS485)

BATTERY-FREE*

Number of Scans (based on default settings)

Fully Charged: Typically more than 450 scans

Ready-to-Go Notification: At least 25 scans (@1 scan/sec)

First Recharge Alert (30%): Typically occurs after 300 scans ±10%

Second Recharge Alert (10%): Typically occurs after 400 scans ±10%

Expected Full Charge Time (completely discharged)

Standard USB: Typically under 120 seconds

Powered USB/External Wall Power Adapter: Typically under 30 seconds

Expected Ready-to-Go Charge Time

Standard USB: Typically under 25 seconds

Powered USB/External Wall Power Adapter:Typically under 15 seconds

Use Time (5 scans/transaction, 1 min/transaction)

Fully Charged: Typically 25 minutes of usage

Ready-to-Go Notification:Typically 5 minutes of usage left

First Recharge Alert (flashing yellow LED): Typically 10 minutes of usage left

Second Recharge Alert (flashing red LED): Typically 5 minutes of usage left

Charge Cycles (from completely discharged):500,000

ENVIRONMENTAL

Scanner:

Operating Temperature: 0°C to 50°C (32°F to 122°F)

Storage Temperature: -40°C to 70°C (-40°F to 158°F)

Humidity: 0 to 95% relative humidity, non-condensing

Drop: Designed to withstand 50 1.8 m (6 ft) drops to concrete

Environmental Sealing: IP42

Light Levels: 0 to 100,000 lux (9,290 ft-candles)

Charge and Communication Base:

Operating Temperature:

Charging: 0°C to 50°C (32°F to 122°F)

Non-Charging: 0°C to 50°C (32°F to 122°F)

Storage Temperature: -40°C to 70°C (-40°F to 158°F)

Humidity: 0 to 95% relative humidity, non-condensing

Drop: Designed to withstand 50 1 m (3.3 ft) drops
to concrete

Environmental Sealing: IP41

Light Levels: N /A

SCAN PERFORMANCE

Scan Pattern: Area Image (838 x 640 pixel array)

Motion Tolerance: Up to 610 cm/s (240 in/s) for 13 mil UPC at optimal focus

Scan Angle:
(SR) Horizontal: 42.4°; Vertical: 33°
(HD) Horizontal: 41.4°; Vertical: 32.2°

Symbol Contrast: 20% minimum reflectance difference

Pitch, Skew:±45°, ±65°

Decode Capability:Reads standard 1D, PDF, 2D, Postal and OCR symbologies (Note: Decode
capabilities dependent on kit configuration.)

Warranty:Three-year factory warranty
